The authentic hardware you need to correctly reassemble the engine components which attach to the long-block. Most fasteners are either meticulous reproductions or New Old Stock. Most items are made in USA to the same standards required by Chrysler.
Master Chassis Hardware Kit Includes:
Part #
Application
Notes
Pcs
C-8338
Accelerator Pedal (B & E Body)
Coni Keps, Coni Sems
6
C-8115
Axle Housing > Springs
1/2-20 X 7.12 U-Bolts, Lock Nuts
12
C-8222
Axle Retaining Nuts
Hx Lock Nuts, Flng Nuts
10
C-8223
Ball Joints W Drum Brakes
Hx Bolts, Slotted Nuts, Pins
12
C-8227
Brake Assembly (Front Drum) > Spindle
Hx Bolts, Split Wa'S, Nuts
12
C-8335
Brake Booster
Ext Keps
4
C-8202
Brake Cable Tension Adjuster
Flange Lock Nut Only
1
C-8177
Brake Drum Retainers
1/2" Stud, Green Push On Retainers
6
C-8228
Brake Hoses > Bracket Clips
U-Clips
3
C-8212
Control Arms (Upr)
Cam Bolts, Washers, Nuts
16
C-8132
Differential Carrier - 8 3/4
Nuts W Nylon Pellet
10
C-8027
Differential Carrier Cover - 9 3/4
3/8" Hx Flng Bolts "E"
10
C-8106
Driveshaft > Flange
Straps, Hx Bolts, Split Wa'S
10
C-8088
Engine Insulator > Body - V8 Exc Hemi
Hx Bolts "38", Coni Wa'S
4
C-8084
Engine Insulator > Eng Brkt - Exc Hemi
Hx Nuts, Coni Wa'S
4
C-8086
Engine Mount Brackets - 383/440
Hx Bolts, 5/8 Af Nuts, Flat Wa'S
19
C-8131
Gas Tank
J-Bolts, Lock Nuts
4
C-8215
Idler Arm
"Tr" Hex Bolt, Tri-Slot Nut, Pin
3
C-8216
K-Frame > Body
Special Hex Coni Sems
4
C-8112
Leaf Spring Mounting @ Front
Hub Bolts, Coni Keps
16
C-8214
Leaf Spring Mounting @ Front
"H" Marked Bolts, Marsden Nuts
4
C-8331
Master Cylinder
Ext Keps
4
C-8333
Master Cylinder Support Plate
Coni Keps, Ext Keps, Sealer
4
C-8229
Parking Brake Control > Body
Ext Keps
3
C-8226
Pitman Arm
Nut, Split Wa
2
C-8203
Proportioning Valve > Apron
Red Flange Lock Nut
1
C-8113
Shackles - Nuts Only
Hx Nuts
4
C-8109
Shocks (Fr) - Lwr Mounting
Hx Bolts "Tr" Or "D", Lock Nuts
4
C-8120
Shocks (Rr) - Lwr Mounting
Hx Nuts Only
2
C-8119
Shocks (Rr) - Upr Mounting
Hx Bolts, Lock Nuts
4
C-8208
Stabilizer Bar Center Supports
Hx Coni Sems, Hx Nuts
8
C-8124
Steering Gear (B Body)
Hi-Hx Hd Bolts, Split Wa'S
6
C-8178
Steering Linkage
Tri-Slot Nuts, Cotter Pins
12
C-8105
Strut Rod > K-Frame (B & E Body)
5/8-11 Lock Nuts
4
C-8117
Suspension Bumper Brkt > 8 3/4 Axle
Hx Coni Sems "Anchor"
2
C-8157
Suspension Bumper Brkt > 9 3/4 Axle
Hx Coni Sems "Anchor"
3
C-8175
Suspension Bumpers (Fr)
Hug-Lok Nuts
4
C-8118
Suspension Bumpers (Rr)
Hx Coni Sems "Anchor"
4
C-8218
Trans Crossmember
Hx Bolts, Flat Wa'S, Coni Keps
12
C-8095
Trans Insulator > Crossmember
Lock Nut
1
C-8220
Trans Insulator > Trans
Hx Coni Sems
2
C-8337
Wheel Cylinders (4) W 1/4-20
Hx Flng Screws
8
C-8192
Wheel Cylinders (4) W 5/16-18
5/16-18 Hx Ext Sems
8
