The authentic hardware you need to correctly reassemble the engine components which attach to the long-block. Most fasteners are either meticulous reproductions or New Old Stock. Most items are made in USA to the same standards required by Chrysler.
Master Chassis Kit Includes:
Part#
Application
Notes
Pcs
C-8084
Engine Insulator > Eng Brkt - Exc HEMI
HX Nuts, Coni WA's
4
C-8087
Engine Mount Brackets - 273/318/340
HX Bolts, 5/8 AF Nuts, Flat WA's
18
C-8088
Engine Insulator > Body - V8 exc HEMI
HX Bolts "38", Coni WA's
4
C-8095
Trans Insulator > Crossmember
Lock Nut
1
C-8105
Strut Rod > K-Frame
5/8-11 Lock Nuts
4
C-8106
Driveshaft > Flange
Straps, HX Bolts, Split WA's
10
C-8109
Shocks (Fr) - Lwr Mounting
HX Bolts "TR" or "D", Lock Nuts
4
C-8112
Leak Spring Mounting @ Front
Hub Bolts, Coni Keps
16
C-8113
Shackles - Nuts Only
HX Nuts
4
C-8115
Axle Housing > Springs
1/2-20 x 7.12 U-Bolts, Lock Nuts
12
C-8117
Suspension Bumper Brkt > 8 3/4 Axle
HX Coni Sems "Anchor"
2
C-8118
Suspension Bumpers (Rr)
HX Coni Sems "Anchor"
4
C-8119
Shocks (Rr) - Upr Mounting
HX Bolts, Lock Nuts
4
C-8120
Shocks (Rr) - Lwr Mounting
HX Nuts Only
2
C-8124
Steering Gear (B body)
HI-HX HD Bolts, Split WA's
6
C-8131
Gas Tank
J-Bolts, Lock Nuts
4
C-8133
Differential Carrier - 8 3/4
Nuts w/ Nylon Patch
10
C-8175
Suspension Bumpers (Fr)
Hug-Lok Nuts
4
C-8177
Brake Drum Retainers
1/2" Stud, Green Push on Retain
6
C-8178
Steering Linkage
Tri-Slot Nuts, Cotter Pins
12
C-8192
Wheel Cylinders (4) w 5/16 -18
Nuts w/ Nylon Patch
8
C-8202
Brake Cable Tension Adjuster
Flange Lock Nut Only
1
C-8203
Proportioning Valve > Apron
Red Flange Lock Nut
1
C-8208
Stabilizer Bar Center Supports
HX Coni Sems, HX Nuts
8
C-8212
Control Arms (Upr)
Cam Bolts, Washers, Nuts
16
C-8214
Leaf Spring Mounting @ Front
"H" Marked Bolts, Marsden Nut
4
C-8215
Idler Arm
"TR" HEX Bolt, Tri-Slot Nut, Pin
3
C-8216
K-Frame > Body
Special HEX Coni Sems
4
C-8219
Trans Crossmember
HX Bolts, Flat WA's, Lock Nuts
16
C-8220
Trans Insulator > Trans
HX Coni Sems
2
C-8222
Axle Retaining Nuts
HX Lock Nuts, Flng Nuts
10
C-8223
Ball Joints w/ Drum Brakes
HX Bolts, Slotted Nuts, Pins
12
C-8226
Pitman Arm
Nut, Split WA
2
C-8227
Brake Assembly (front drum) > Spindle
HX Bolts, Split WA's, Nuts
12
C-8228
Brake Hoses > Bracket Clips
U-Clips
3
C-8330
Parking Brake Control > Body
HX Coni Sems, Coni Keps
3
C-8332
Master Cylinder
HX Lock Nuts
4
C-8333
Master Cylinder Support Plate
Coni Keps, EXT Keps, Sealer
4
C-8336
Brake Booster
HX Lock Nuts
4
C-8337
Wheel Cylinders (4) w 1/4-20
HC Flng Screws
8
C-8338
Accelerator Pedal
Coni Keps, Coni Sems
6
